The Mini SSC II is a small electronic interface that connects to a Palm PDA or a Macintosh computer and can control eight servos under simple code control.

The Mini SSC II is a fully assembled module that includes a convenient phone-style jack for serial cable hookup, Futaba-J type servo output headers, a sync LED to indicate when valid data is received, and servo range/resolution position control.

The Mini SSC II generates eight channels of precise, stable servo-control pulses which send the specified servo to move to the commanded position of a 90° range with 0.36° resolution, or up to 180° and 0.72° resolution motion control. Servos are held in the last commanded position until instructed to move to new position by command code sent to the interface. The Mini SSC II is operated from 9 Vdc, and the servos from 6 Vdc.

Complete kit to build Palm Pilot Robot

This custom made cable is configured to correctly connect to the serial port of a Palm III series hand held device and to the Mini SSC II Interface board without having to use adapters and various cables.

A special plug-in connector for the Palm PDA serial port is at one end of the cable with the other end of the cable connected to a RJ-10 four wire connector.The RJ-11 wire connection to the cable is re-enforced for strength.

The cable is three feet in length.
